Gecko IN.YE-3-V2 Control Box with 3kW Heater
The Gecko IN.YE-3-V2 control box is a compact, high-performance spa control system built for versatility, reliability, and ease of installation. Suitable for both entry-level hot tubs and advanced swim spas, it supports up to 3 pumps and features a powerful 3kW heater, integrated temperature probe, and IPX5-rated waterproof casing.
Key Features:
-
Supports 1, 2 or 3 pumps
-
Includes 3kW, 2” x 15” flow-through heater with built-in temperature probe
-
IPX5 waterproof rated design
-
Solid-state flow detection – no pressure switch needed
-
Self-diagnostic system with overheat and freeze protection
-
Programmable filter cycles
-
12V AC light support
-
3 configurable relays
-
Compatible with in.touch Wi-Fi module for smart control https://www.wizardhottubs.co.uk/product/gecko-in-k1001-topside-control/
-
Corrosion-resistant enclosure
-
Connector type: AMP with quick-connect; JJM adaptor available
-
System Specs at a Glance:
-
Heater: 3kW
-
Pump Support: Up to 3 pumps
-
Circulation Pump: Yes
-
Blower: No
-
Ozone: Yes
-
Lights: Yes
-
Wi-Fi: Optional (via in.touch module)
-
Audio: Not supported
-
This unit must be fitted by a competent individual or tradesman. Incorrect installation could invalidate the warranty.
